What is a Weld Crack in Welding?

A weld crack is a type of discontinuity that can occur in the weld metal or heat-affected zone of a welding joint. Cracks are often the result of poor weld design, incorrect welding procedures, or excessive stresses on the joint during service. Weld cracks can lead to premature failure of the joint and must be repaired before the joint can be used.

What are the types of weld crack?

Weld cracks can be classified into three main types:

  1. Hot cracks occur during the welding process, while the metal is still hot and under stress. These cracks are typically caused by improper weld procedures or inadequate weld cooling.
  2. Cold cracks occur after the welding process is complete, as the metal cools and contracts. These cracks are often the result of poor weld design or welding over dirty or rusty metal.
  3. Fatigue cracks occur during service as the joint is subjected to repeated loading and unloading. These cracks are often caused by improper weld design or welding over metal that is already fatigued.

What are the 5 causes of weld crack?

There are five main causes of weld crack:

  1. Poor weld design.
  2. Incorrect welding procedures.
  3. Excessive stresses on the joint during service.
  4. Welding over dirty or rusty metal.
  5. Welding over metal that is already fatigued.

How can weld cracks be prevented?

Weld cracks can be prevented by using proper welding procedures, designing the joint properly, and avoiding excessive stresses on the joint during service.

How to fix cracks in welding?

The most common method of repair is to weld over the cracked area with a filler metal that is compatible with the base metal. The repaired joint must then be heat treated to relieve the stresses that caused the crack. In some cases, it may also be necessary to replace the entire section of the weld.

Crater cracks in welding are caused by

There are several possible causes of crater cracks, including:

  • The use of an incorrect welding procedure.
  • Poor weld design.
  • Excessive stresses on the joint during service.
  • Welding over dirty or rusty metal.
  • Welding over metal that is already fatigued.
