What is Depth of Bevel in Welding?

The depth of bevel (DoB) is the perpendicular distance from the base metal surface to the root edge of the beginning of the root face. It’s a critical factor in welding, as it helps determine how much weld metal will be required to fill the joint. Too little weld metal can lead to poor fusion and lack of strength, while too much weld metal can cause distortion and crack.

Depth of bevel also affects the appearance of the weld. A shallower bevel will result in a narrower bead, while a deeper bevel will create a wider bead. In some cases, specific bead width is required for aesthetic or functional purposes.

The depth of bevel can be controlled through the use of different welding techniques and tools. For example, a welding torch can be used to create a shallow bevel, while a grinding wheel can produce a deeper bevel.

Depth of bevel is just one of many factors that must be considered when planning a weld. Other important factors include:

  • joint configuration,
  • metal thickness,
  • and welding process.

By taking all of these factors into account, you can ensure that your welds are strong and attractive.

What is the depth of preparation in welding?

Depth of preparation is the perpendicular distance from the base metal surface to the root edge of the beginning of the root face. It’s a critical factor in welding, as it helps determine how much weld metal will be required to fill the joint. Too little weld metal can lead to poor fusion and lack of strength, while too much weld metal can cause distortion and cracking.

What is the typical weld bevel angle?

There is no single answer to this question, as the weld bevel angle will vary depending on the joint configuration, metal thickness, and welding process. In general, shallower bevels are used for thinner materials, while deeper bevels are used for thicker materials. The angle of the bevel also affects the appearance of the weld. A shallower bevel will result in a narrower bead, while a deeper bevel will create a wider bead.

What is the difference between depth of bevel and depth of penetration?

Depth of penetration (DoP) is the distance that the welding arc penetrates into the base metal. It’s measured from the surface of the base metal to the center of the weld pool. Depth of bevel, on the other hand, is the perpendicular distance from the base metal surface to the root edge or the beginning of the root face. It’s measured from the surface of the base metal to the point where the weld bead meets the root edge.

Depth of bevel weld symbol

The depth of bevel is indicated on welding symbols by a short leader line with an arrow pointing to the root edge or beginning of the root face. The depth of bevel is typically specified in millimeters (mm) or inches (in).

  • For example, a symbol that shows a depth of bevel of 3 mm would look like this:

DoB=3 mm

  • A symbol that shows a depth of bevel of 1/4 inch would look like this:

DoB=1/4 in

Good to know:

1) Groove weld size

The depth of bevel, along with the groove angle and root opening, determines the size of the groove weld.

2) Double v groove weld

In a double v groove weld, the depth of bevel is equal to half the plate thickness.
